What is P and junction diode?
0:02
Definition. A P and junction diode is a
0:04
semiconductor device formed by joining
0:07
AP type and an untyped semiconductor
0:10
allowing current to flow easily in one
0:12
direction while blocking it in the
0:14
opposite direction. Explanation when AP
0:17
type semiconductor with holes as
0:20
majority carriers is joined to an
0:22
untyped semiconductor with the electrons
0:24
as majority carriers, a junction is
0:27
formed at the boundary. Free electrons
0:29
from the unside diffuse into the Pside
0:32
and combine with holes. This creates a
0:35
depletion region with a mobile ions and
0:37
an electric field. The built-in
0:40
potential barrier prevents further
0:42
movement of carriers. If the diode is
0:44
forward biased, positive voltage on
0:47
Pside, negative onside, the barrier is
0:50
reduced and current flows. If reverse
0:53
biased, the barrier increases and almost
0:56
no current flows except a tiny leakage
